Aluminium Cutting Blade
JY-AC Standard Quality
Aluminium Cutting Blade
· Suitable for cutting aluminium alloy materials,non-ferrous metals and some other materials with high quality and long cutting life
| Item No. | Diameter | Teeth No. | Kerf | Plate Thickness | Arbor | |
| inch | mm | mm | mm | mm | mm | |
| JY-AC-110 | 4" | 110 | 20/40 | 2.0 | 1.2 | 16 |
| JY-AC-115 | 4½" | 115 | 40 | 2.0 | 1.2 | 16 |
| JY-AC-125 | 5" | 125 | 30 | 2.0 | 1.4 | 20 |
| JY-AC-165 | 6½" | 165 | 30 | 2.2 | 1.6 | 20 |
| JY-AC-180 | 7" | 180 | 40/60/80 | 2.2 | 1.6 | 22.2 |
| JY-AC-215 | 8¼" | 215 | 30/40/60/80 | 2.4 | 1.8 | 22.2 |
| JY-AC-250 | 10" | 250 | 60/80/100 | 2.8 | 2.2 | 25.4 |
| JY-AC-300 | 12" | 300 | 60/80/100/120 | 3.2 | 2.2 | 25.4 |
| JY-AC-350 | 14" | 350 | 60/80/100/120 | 3.4 | 2.5 | 25.4 |
| JY-AC-400 | 16" | 400 | 60/80/100/120 | 3.4 | 2.5 | 25.4 |
